Ozone Generator

Home > Products > Ozone Generator > Ozone Generator

Ozone Generator TCB-57

Share:
Products Details

Ozone Generator    TCB-57


型号/Type   No输入电压/IP功率/Power电流/Current臭氧量
    /ozone@pure O2
负载/Load推荐使用/Recommed   for
TCB-5750A1CAC100-130V 50/60HZ<8W<100mA50mg/h陶瓷片/
    Ceramic plate
空气净化器,气味消除机,农场驱鼠驱虫,酒店/公共区域空气消毒。
    Air purifiers, odor eliminators, farm repellers, air disinfection in   hotels/public areas.
TCB-57100A1C(LL)100mg/h
TCB-57200A1C(LL)200mg/h
TCB-57300A1CLL300mg/h
TCB-5750A2CAC200-240V 50/60HZ<8W<100mA50mg/h陶瓷片/Ceramic plate
TCB-57100A2C(LL)100mg/h
TCB-57200A2C(LL)200mg/h
TCB-57300A2CLL300mg/h
TCB-5750D12CDC12V<8W<650mA50mg/h陶瓷片/Ceramic plate
TCB-57100D12C(LL)100mg/h
TCB-57200D12C(LL)200mg/h
TCB-57300D12CLL300mg/h
TCB-57200A1VAC100-130V   50/60HZ<8W<100mA200mg/h有机玻璃管/
    PVC ozone tube
饮水机,足浴盆,洗碗机,消毒机,按摩浴缸,洗衣机等家电产品
    Drinking fountains, foot tubs, dishwashers, disinfectors, jacuzzi, washing   machines, etc.
TCB-57500A1V500mg/h
TCB-57200A2VAC200-240V 50/60HZ200mg/h
TCB-57500A2V500mg/h
TCB-57200D12VDC12V<650mA200mg/h
TCB-57500D12V500mg/h
备注Remark:
    1.   括号中的“LL"是可选的,表示此型号负载为长寿型陶瓷片,常规陶瓷片寿命达>1800小时,长寿型陶瓷片寿命>3500小时,例如,TCB-57100A1C的负载为普通陶瓷片,TCB-57100A1CLL   的负载则为长寿型陶瓷片。
    The "LL" in parentheses is optional, indicating that load of this   type a long-life ceramic piece. The life of a conventional ceramic piece is   >1800 hours, and the life of "LL" type ceramic piece is >3500   hours. For example, the load of the TCB-57100A1C is a common ceramic piece.   The load of TCB-57100A1CLL is "LL" ceramic piece.
    2. 有机玻璃管系列建议连接2~3L/min 气泵或者射流器使用。
    PVC ozone tube should be connected with 2~3/L air pump or venturi when using
    3. 陶瓷片系列建议配合风扇使用
    Ceramic sheet series will be  better if use togther with fans
